NO LOOSE ENDS

Build, route, measure, power, tear down, rebuild, and rework the rig as you go. From pedalboards to stages and studios, Kordmate keeps the connections clear enough to stick through every change.

PedalboardsTouring & IEMStagesStudiosDMX

ONE WORKSPACE, VERY DIFFERENT RIGS

Screenshot placeholder

PEDALBOARD SCENE

A pedalboard laid out on the Canvas: patch cables, amp send/return and power routing all visible.

Σ PATCH 2.4 M · 410 mA @ 9 V DC

TOURING RACK SCENE

A rack documented front to back: IEM signal flow, balanced and unbalanced runs, power distribution.

BAL XLR · UNBAL TS · PWR DIST 10 A

STAGE PLAN SCENE

A stage plan with the multicore routed around the riser to FOH, slack and labels included.

MULTI 24CH → FOH 30 M · SLACK +1.5 M

STUDIO PATCHBAY SCENE

Patch points, monitoring and the permanent runs hidden in the walls. Documented, not memorized.

TRS 6.3 MM · PERMANENT WALL DUCT

DMX ROUTING SCENE

A DMX universe daisy-chained along the truss and routed around the LED wall.

DMX512 U1 · ADDR 001–016 · TERM 120 Ω

Also in use for

Event diagrams for rental music equipmentFixed stage & AV documentationSystem planning & proposals for music and AV teamsPermanent installationsStudio patchbay documentationCable labeling & routing

REAL QUESTIONS, ANSWERED ON THE CANVAS

WILL THIS CABLE REACH?

Required cable lengths come straight from the Scene, before you buy, cut or crawl under a stage.

Screenshot placeholder

CABLE LENGTH CHECK

An amp placed across the Scene, with the required run calculated against the cable in use.

REQUIRED 4.2 M · 3 M CABLE TOO SHORT

Screenshot placeholder

POWER BUDGET

Per-pedal current draw summed against the supply's capacity, with the overload flagged.

Σ 530 mA / 500 mA · OVER BUDGET

CAN THIS SUPPLY HANDLE THE BOARD?

Every device carries its current draw. The board answers before the fuse does.

WHERE DOES THIS SIGNAL GO?

Pick any device and follow its complete signal path through the Scene.

Screenshot placeholder

SIGNAL PATH TRACE

One device selected, its downstream path highlighted while the rest of the Scene steps back.

GTR → PEDALS → MIXER → FOH

PLANS CHANGE.
THE DOCUMENTATION CAN TOO.

Move, swap or add a device. The cables re-route, the numbers follow, and the Scene stays readable.

Screenshot placeholder

RE-ROUTED IN SECONDS

Before and after: the delay pedal moved to the shelf, cables re-routed, patch total updated.

Σ PATCH 1.9 M → 2.6 M

TEAR IT DOWN. KEEP EVERYTHING.

The rig can disappear, move or change. The information needed to understand and rebuild it remains.

Screenshot placeholder

SCENE ASSEMBLED

The working Scene: devices placed, cables routed, lengths and current live.

5 DEVICES · 4 CABLES

SNAPSHOT SAVED

A fixed, dated version of the Scene preserved alongside the working copy.

RIG V2 · SAT 21:14

RIG PACKED AWAY

Flight cases in the van. The physical rig is gone. The documentation is not.

DOCUMENTATION INTACT

REBUILT FROM THE SNAPSHOT

The same rig, rebuilt from its Snapshot, ready to export or share.

EXPORT PDF · SHARE LINK

FOCUSED BY DESIGN

Screenshot placeholder

A DENSE SCENE, STILL READABLE

A busy Scene that stays legible: lengths, current draw and labels shown only where needed.

LENGTHS · CURRENT · LABELS · ON DEMAND

  1. 1

    Readable as complexity grows: more devices and routes, same clarity.

  2. 2

    Technical when it needs to be: lengths, current draw and labels on demand, never in the way.

  3. 3

    Purpose-built for connected equipment, not another generic diagramming tool.

Ready to connect?

Turn your setup into a clear plan.

Open the Kordmate workspace and try it now. No sign-up or download required.
